Wall-Mounted Automated Handwashing System

CleanTech® EVO Wall

The EVO Wall is our wall-mounted CleanTech® Automated Handwashing Station. This durable system features a watertight cabinet designed for wall mount in high-use areas in both industrial production and commercial environments. Deep cylinders provide effective handwashing beyond wrists to forearms to quickly remove more than 99.9% of pathogens in just 12 seconds.

Request a Custom Quote Technical Specs

Engineering Details

Technical Specifications

Fully compliant, heavy-duty industrial specifications designed for sterile and high-capacity facilities.

Water Consumption

0.7 gallons (2.65 L) per 12-second hand wash cycle

Electrical Connection

6' power cord included, 100-250 VAC, NEMA 5-15p (International plugs available)

Plumbing Requirements

Water supply hoses included, 1/2" MNPT H&C - ASSE 1070 Thermostatic Mixing Valve, 35-100 PSI / 4 GPM minimum, 3/8" ID supply line minimum (Consult our technical support if connecting more than two stations on the same water lines)

Drainage Requirements

1 1/4" or 1 1/2" Slip Drain, P-Trap included

Required Hand Hygiene Solution

2,000 mL UltraPure Hand Hygiene Solution (2,000 hygiene events)

Optional SelfClean Solution

2,000 mL SelfClean system cleaning solution

System Features

Functional Advantages

12-second wash and rinse cycle activates automatically via infrared photo-optical sensors

Compliance monitor automatically counts number of hand wash cycles

Designed for high-use areas

CIP (Clean-in-Place) friendly with NEMA 4X electronics enclosure

Washes up to mid-forearm for comprehensive hygiene

Full color display with wash cycle countdown timer and hygiene tips for employee training and education

Value Delivered

Key Benefits

Ensures Hygiene SOP Compliance

Automated wash cycle and compliance monitor make meeting standard operating procedures effortless and trackable.

Removes 99.9% of Pathogens

Proven to remove more than 99.9% of dangerous pathogens in just 12 seconds of contact.

High Throughput

Rapid washing accommodates up to 4 employees per minute per station, keeping your lines moving.

Water Efficient

Uses significantly less water than standard manual hand washing methods, saving resources.

ORDER NOW

Get a Custom Quote for Your Facility

If you need custom installation or layout guidance, contact us today.

Get a free, no-obligation quote tailored to your specific contamination control and hygiene requirements. Our experts will help you determine the optimal configuration and solutions for your facility.

Request a Quote
